8-1/4 In. Wormdrive Saw

HD5860

Bosch

Wormdrive Saw
(click image to enlarge)
Quick Overview
  • Exclusive 60° bevel feature with 8-1/4 In. blade is ideal for angled cuts
  • High torque 13 A motor
  • Precision-machined worm drive gears for maximum power
  • Oil indicator level and relief bellows for long life
  • Die-cast aluminum motor and gear housings for durability
  • 22 Amp switch and heavy gauge cord for dependability
Interested in this item or want more information?

Phone: (800)-430-1417
Email: teri.collins@yoshissupply.com

Can't find what you want? Give us a call and we can help you find it.
Details
  • Powered Tool Power Source: Electric - Corded
  • Saw Drive: Worm Drive Geared
  • Saw Blade Diameter (in): 8¼ in
  • Cordless / Corded: Corded
  • Blade Location: Left
  • Horsepower (hp): 2.5
  • Maximum RPM - No Load: 4300
  • Depth Adjustment: Yes
  • Maximum Cut Depth @ 45° (in): 2.25
  • Maximum Cut Depth @ 90° (in): 2.875
  • Bevel Capacity (°): 60
  • Bevel Stop: Yes
  • Miter Saw - Preset Bevel Angle Detents (°): Not Featured
  • Tool Weight (lbs): 18.8
  • Arbor Size (in): 0.625
  • Electric Motor Brake: No
  • Voltage: 120
  • Amperage (A): 13
  • Wattage (W): 1560
  • Cord Length (in): 8
  • External Motor Brush Access: No
  • Shoe Material: Steel
  • Housing Material: Aluminum, Plastic
  • Fence Included: No
  • Tool-Less Blade Changing: No
  • Blade Wrench Included: Yes - Loose
  • Integrated Laser Guide: No
  • Guide(s): Rip Fence Sold Separately
  • Integrated Rafter Hook: Not Featured
  • Integrated Work Light: Not Featured
  • Dust Blower: No
  • Dust Collection: Yes
  • Dust Port: No
  • Length (in): 21.1
  • Height (in): 8
  • Main Handle Type: Rear
  • Color / Finish: Gray
  • Spindle Lock: No
  • Blades Included: 1
  • Tool Storage: No Case Included
  • Package Contents: Saw, Combination Blade, Blade Wrench
  • Warranty: Limited 1 Year
  • CSA Certified: No
  • ETL Listed: No
  • UL Listed: Yes
    • Additional Information
    Manufacturer: Bosch
